Zhejiang IRONFLON Wire & Cable Co., Ltd. is one of the most professional manufacturers and suppliers of 3 core flexible wire in China, also supports customized service. Please feel free to buy high quality 3 core flexible wire for sale here from our factory. Also, free sample is available.
Products Description
UL1180 3 core flexible wire
3 Core Copper Wire Conductor Construction
22 AWG conductors consist of multiple strands of nickel-plated copper wire stranded to ensure stability and flexibility for high frequency signal transmission. The three-core design allows for multi-circuit wiring and reduces space requirements.
3 core copper wire insulation and jacket
PTFE (Teflon) insulation with uniform thickness covering the conductor.
Color support for customization (white/blue/red/black, etc.).
3 core copper wire Certifications and Standards
Comply with UL758, rated voltage 300V, temperature range -65℃ to +200℃, passed VW-1/FT1 flame retardant test.
Key performance advantages of UL1180 3 core flexible wire
Extreme Environmental Adaptability
High Temperature Resistance: Continuous working temperature of 200℃, short time resistance of 300℃ (e.g. motor overheating protection scenarios);
Chemical Stability: Resistant to acid and alkali, oil, mildew and suitable for industrial machinery oil pollution environment. ;
Low Temperature Flexibility: -65℃ still maintains the bending performance, suitable for freezing equipment wiring;
Electrical and safety features
Dielectric strength: 2500V industrial frequency voltage withstand test (far more than conventional 300V cable);
Coating protection: nickel-plated conductor antioxidant, reducing signal attenuation;
Product Date
| Product Name | UL1180 3 core flexible wire |
| Diameter | 22 AWG 3 core |
| Color | Any color is ok |
| Rated Temperature | 200 ℃ |
| Rated Voltage | 300V |
| Kind Of Insulation | PTFE |
| Conductor Material | Nickel plated |
| Length | 1000FT/305M |
Why choose us
Most of the wire is easy to aging,cause fire hazard flame retarancy is poor,easy to overload short circuit fire,once the short circuit,melt immediately.We usd high purity copper materials,it means our wires have anti-aging,high conductivity,low energy consumption,strong current load capacity.And our wires comply with various testing standards,multiple quality check.
By sticking to quality levels,our wires can be used in a variety of scenarios.Our wires can be used inside the lamp,machine Mechanical arm ,car interior household appliances and project.
To provide customers with quality products and satisfactory service,our company adopts the production line of advanced flowing water and high-quality raw materials,from production to packaging, everything is done on site.And we will be actively helping customers solve problems to gain an advantage in the competition.
Application scenarios of 3 core shielded cable
1. High Temperature Home Appliances Core Wiring
Kitchen Appliances
3 Core Shielded Cable can be used for microwave oven magnetron power supply, oven heater connecting wire, withstand 200℃ continuous high temperature and pass VW-1 flame retardant test, solve the safety hazard of traditional wires in the confined high temperature environment.
Air conditioning system
3 Core Shielded Cable is suitable for compressor circuit wiring, -65 ℃ low-temperature characteristics to prevent the refrigerant environment embrittlement, three-core color-coded design to facilitate the distinction between the power supply/signal lines.
2. Industrial Automation Equipment
Electromechanical Control System
3 Core Shielded Cable is suitable for servo motors, injection molding machine heating rings and other high-temperature wiring, nickel-plated conductor antioxidant characteristics to extend the life of the equipment.
Instrumentation
3 core electrical wire can be used for PLC control cabinet signal transmission, PTFE insulation layer to reduce signal interference, flexibility to adapt to the narrow space installation.
3. Transportation
Automobile engine compartment
3 core electrical wire can withstand 200℃ high temperature and vibration environment, can be used for oxygen sensor, turbocharger circuit, through the car-grade anti-fatigue test.
Rail transportation
3 core electrical wire can be used as lighting system connecting wire, its high flexibility design (>1 million times bending) can adapt to the continuous vibration of the vehicle.
Certificate Informat
Packing & Deliver
1. ROSH plastic film packaging ensures that the goods meet ROSH requirements. Place it in the designated location, and the goods will follow FIFO (first in, first out).
2. The common packaging quantities are based on our standards, and if customers have special requirements, we can also customize them. Each batch of goods is acceptable.
3. Support testing reports and provide COC according to customer requirements.
4. We will choose different transportation methods according to the customer's needs. Such as sea freight, air freight, express delivery, etc.
FAQ
Q: How does you company control the quality?
A: Our company has a team of experienced QC,who do in-line and finished goods inspection, we even got certificate of ISO9001 Our products have been certified by UL,RoHS etc.
Q: When Can I Get The Price?
A: We usually quote within 12 hours after we get your inquiry. elf you are very urgent to get the price, please call user tell us in your e-mail so that we will regard your inquiry priority.
Q: How Long Is Your Delivery Time?
A: The general delivery time is 10-15 days after order confirmation. In addition, if you need this product, we have it in stock and the delivery time is 1-2 days after order confirmation. You can consult our salesperson for specific details.
Q: How Can We Get A Quote?
A: Contact us with specification: such as material, size, color, quantity, etc.
Q: What's Your MOQ?
A: If we have the products in stock, it will be no MOQ. If we need to produce, we can discuss the MOQ according to customer's exact situation.
Q: Can I get a discount?
A: It depends on your quantity, We can make a discount and afford the freight. Pls kindly contact us.
Q: Can You Ship Directly To Our Local Area?
A: Of course, you can provide your address and we will offer a suitable transportation plan, including shipping methods and fees. Alternatively, if you have a cooperating Chinese freight forwarder, we can also help you ship to the freight company.
