Zhejiang IRONFLON Wire & Cable Co., Ltd. is one of the most professional manufacturers and suppliers of nickel coated copper wire in China, also supports customized service. Please feel free to buy high quality nickel coated copper wire for sale here from our factory. Also, free sample is available.
Basic characteristics of UL3266 Nickel coated copper wire
Electrical Parameters
Rated temperature: 125℃ (long-term working temperature);
Rated voltage: 300V, suitable for internal connection of low-voltage electrical equipment;
Conductor specification: 20AWG, single or stranded tinned/bare copper wires, with stable conductivity.
Material and structure
Conductor: high purity copper, tinned to enhance oxidation resistance;
Insulation: cross-linked polyethylene (XLPE), through the irradiation process to form a three-dimensional mesh structure, high temperature and chemical corrosion resistance;
Environmental protection certification: RoHS-compliant, halogen-free, low-smoke flame-retardant, no release of toxic gases in the event of a fire; Environmental certification: RoHS-compliant, Halogen-free, low-smoke flame-retardant, no release of toxic gases in the event of a fire.
Safety Certification
Passed UL VW-1 and CSA FT1 vertical combustion test, excellent flame retardant performance;
Conforms to UL758 and UL1581 standards.
Core advantages of UL3266 20 gauge electrical wire
High temperature resistance
The irradiation crosslinking technology keeps the insulation layer stable at a high temperature of 125 ℃ and can withstand a baking environment of 180 ℃ in the short term.
mechanical strength
The insulation layer has a uniform thickness, is easy to peel off and cut, and is convenient for installation;
Stretching resistant, oil resistant, acid and alkali resistant, suitable for complex industrial environments;
Safety and Environmental Protection
Halogen free design reduces fire risk and complies with EU REACH environmental requirements.
Application Scenarios of UL3266 20 gauge electrical wire
Electrical and electronic field
Internal wiring of computers and home appliances, such as motor lead wires and control board connections;
Industrial equipment
Sensors, instrumentation wiring in high temperature resistant environment;
New energy and automobile
Internal connection of some in-vehicle electronic equipments (need to cooperate with other protective designs).
Product Date
| Product Name | UL3266 Nickel coated copper wire |
| Size No. | 20AWG |
| Color | Any color is ok |
| Rated Temperature | 125 ℃ |
| Rated Voltage | 300V |
| Kind Of Insulation | XLPE |
| Conductor Material | Nickel coated copper wire |
| Flame Rate | VW-1 |
Company Profile
IRONFLON Wire&Cable Co., Ltd. was founded in 2004 and is headquartered in Yueqing Economic Development Zone. It is a high-tech enterprise that integrates research and development, manufacturing, and sales. The company focuses on the high-end special cable field, with 8 fluororesin production lines and 2 cold push production lines, with a monthly production capacity of 7500 kilometers. Its products cover multiple fields such as military aerospace and civil communication.
Core advantages
Leading technology
Having multiple patents and international certifications (UL, CUL), mastering the three typical production processes of fluororesin cables.
The R&D team is composed of senior industry experts and invests a huge amount of funds annually in technological innovation.
Quality Assurance
Establish a full process quality control system through international management system certifications such as ISO9001 and IATF16949.
The testing center is equipped with advanced equipment to ensure that the product's high temperature resistance, corrosion resistance, and other performance reach the industry-leading level.
Service and Market
Our products are exported both domestically and internationally, with customers covering fields such as military, electronics, and new energy.
Provide customized solutions with industry-leading response speed, and set up offices in Ningbo and other places to ensure localized services.
production process
1.Conductor Processing
Drawing Process: Using copper raw material, gradually reduce the wire diameter through drawing machine with precision molds to ensure that the conductor size is accurate and the surface finish meets the standard.
Monofilament annealing: high-temperature recrystallization of metal monofilaments to enhance the conductor toughness and conductivity, while strictly preventing oxidation.
Conductor stranding: through the bundle stranding, concentric compound stranding and other processes will be multiple monofilaments stranded into a regular conductor structure, to enhance the mechanical strength and optimize the distribution of current.
2. Fluorocarbon Resin Insulation Manufacturing (Core Technology)
Insulation Extrusion: Special extruder is used to extrude fluorocarbon resin materials such as fep, xlpe, pfa, etc. at high temperature. The barrel temperature is accurately controlled at 270-400℃, and with the metering screw with compression ratio of 3:1, a uniform insulation layer with thickness of 0.01-0.2mm is formed.
Cold push and sintering: For cables with complex structure, the fluorine resin molecular structure is stabilized by cold push process and then high temperature sintering to ensure the insulation layer is resistant to high temperature and chemical corrosion.
Film wrapping: Some products are wrapped with multi-layer fluorocarbon resin film, which is sintered to strengthen the bonding force between the layers.
3. Cable formation and shielding processing
Cable stranding: multiple insulated cores are stranded into cables according to the rules, filling the gaps and wrapping the buffer layer to maintain structural stability.
Shield processing: using braiding or winding process to cover the metal shielding layer (such as tinned copper wire), to effectively suppress electromagnetic interference.
4. Sheathing and Armoring
Inner Sheathing: Extruded isolation sleeve or wrapped cushion layer to protect the core from armor damage.
Metal armor: according to the application scenario, choose steel belt (compressive) or steel wire (tensile) armor to enhance the mechanical protection ability.
Outer sheath: final extrusion of wear-resistant, flame-retardant fluorocarbon resin sheath to realize moisture, corrosion resistance and environmental protection.
5. Closed-loop quality control for the whole process
Online monitoring: real-time monitoring of core parameters such as drawing tension, extrusion temperature and stranding pitch.
Sealing test: Leakage checking of finished products with coil pressure to ensure insulation integrity.
Electrical Performance Verification: High-voltage testing of insulation strength and recording of fan operating parameters to ensure conductive stability.
Certificate Informat
CERTIFICATIONS IN INTERNATIONAL AND DOMESTIC
UL AND CUL Certification ( Reference E252458)
VDE certification
QALITY CERTIFICATION:ISO9001:2005 AND IATF16949
All product can meet ROSH ,REACH
Packaging & Shipping
1. Customized Packaging Process
Reel Protection: Cable products are wrapped with moisture-proof materials and fixed on wooden/iron reels, the outer layer is fitted with anti-collision corners and sealed with film, which can effectively resist extrusion and the influence of humid environment during transportation.
Labeling system: Product model, length, batch number and international common markings such as "up" and "moisture-proof" are marked at prominent positions in the packing boxes, and bilingual labels are attached to export products to facilitate cross-border customs clearance. Bilingual labels are attached to export products to facilitate cross-border customs clearance.
Filling reinforcement: High-strength polypropylene mesh filling rope is embedded between the cable layers to cushion the impact of external forces and ensure the structural stability of the reel (in line with ROHS environmental standards).
2. Intelligent logistics management
Transportation carrier: matching van or container transportation according to the order quantity, equipped with GPS positioning system in the van for real-time monitoring of location and temperature and humidity.
Supplier control: Strict screening of logistics service providers, through the KPI assessment form to assess the transportation time, cargo damage rate and other key indicators, eliminating unqualified partners.
Abnormal Response: If an accident occurs during transportation, the contingency plan will be activated immediately:
Re-dispatch the transportation capacity to make up for the goods within 2 hours;
Synchronize with the customer to inform the progress and provide loss voucher documents.
3. Cross-border Delivery Guarantee
Export Compliance: Imported and exported goods are insured throughout the whole process, and the customs declaration documents are examined by specialized personnel to ensure compliance with the safety certification of cables and cables in the target countries (e.g. UL, VDE).
Information Transparency: Customers can track the flow of goods in real time through the system.
Arrival Confirmation: Verify the integrity of the outer packaging with the consignee within 24 hours after unloading, and keep the signing record for archiving.
FAQ
Q: What about the lead time for mass production?
A: Our production capacity is sufficient,normally 15-20 days we can deliver your order. only if quantity is big, we'll offer you.
Q: When Can I Get The Price?
A: We usually quote within 12 hours after we get your inquiry. elf you are very urgent to get the price, please call user tell us in your e-mail so that we will regard your inquiry priority.
Q: How Long Is Your Delivery Time?
A: The general delivery time is 10-15 days after order confirmation. In addition, if you need this product, we have it in stock and the delivery time is 1-2 days after order confirmation. You can consult our salesperson for specific details.
Q: Do You Have After-Sale Service?
A: Yes, Good after-sale service, handling the customer complaint and solve problem for customers.
If You Have Any Other Questions, Please Send An Email To Luna@Ironflon.Com We Will Respond Promptly.
