Zhejiang IRONFLON Wire & Cable Co., Ltd. is one of the most professional manufacturers and suppliers of ul 1332 wire in China, also supports customized service. Please feel free to buy high quality ul 1332 wire for sale here from our factory. Also, free sample is available.
UL 1332 is a FEP perfluoroethylene propylene insulated high-temperature electronic wire produced according to the UL758 standard. It is a core wiring product for industrial high-temperature, precision electronics, and harsh working conditions. Zhejiang IRONFLON Wire&Cable Co., Ltd. has been deeply involved in the high-temperature cable industry for many years, strictly following UL certification standards and RoHS environmental standards to create a full range of UL 1332 wire. It adopts a composite structure of high-purity conductors and high-quality FEP insulation layer, perfectly adapting to a wide temperature range of -65 ℃ to 200 ℃ continuous working environment.
This UL 1332 standard wire has a rated voltage of 300V and excellent high-temperature resistance, flame retardancy, corrosion resistance, aging resistance, high insulation, and low loss characteristics. As a high-quality single core flexible cable, the wire has low eccentricity and uniform insulation wall thickness, effectively eliminating hidden dangers such as high-voltage breakdown, ignition, and leakage. At the same time, the wire has excellent flexibility, bending resistance, easy peeling and cutting, and strong processing adaptability. It is widely used in internal wiring, signal transmission, and circuit connection in fields such as home appliances, industrial control, new energy, medical, aerospace, and precision instruments. It is the preferred wire for high-temperature resistant wiring of high-end precision equipment.
Strong Processing Adaptability: The wire body is smooth and flexible, resistant to repeated bending, tensile and wear-resistant, easy to peel without cracking or peeling, convenient for cutting, terminal crimping, and welding processing, and compatible with automated equipment for mass production and processing, effectively improving customer production efficiency.
Product Parameters
| Product name | UL 1332 wire |
| Rated temperature | -65 ℃~+200 ℃ (long-term continuous operation) |
| Rated voltage | 300V |
| Insulating material | High quality FEP perfluoroethylene propylene |
| Conductor specifications | 10AWG-30AWG (Special specifications can be customized) |
| Color | Conventional colors, such as black, white, red, yellow, green, blue, brown, gray, orange, etc. (customizable) |
| Conductor material | Silver plated copper, tin plated copper, Nickel Plated Copper (On-demand customization) |
| Flame retardant rating | Passed VW-1 and ROHS tests |
Comparison of conductor materials
Our UL 1332 standard wire supports three mainstream high-end conductor materials, adapting to different working conditions, budgets, and performance requirements. Differentiated selection is clear and intuitive:
| Conductor material | core advantage | Applicable scenarios | Cost effective positioning |
| tinned copper wire | Anti oxidation, anti-corrosion, easy to weld, stable conductivity, strong toughness and not easy to break, suitable for conventional high temperature environments, long service life. | Home appliances, general industrial control, power wiring, conventional electronic devices. | High cost-effectiveness, a universal mainstream choice. |
| Silver plated copper wire | Higher conductivity, excellent high-frequency transmission performance, high temperature oxidation resistance, extremely low signal loss, strong anti-interference ability. | Precision instruments, high-frequency equipment, medical electronics, signal transmission lines. | Mid to high end, specifically designed for precision scenes. |
| Nickel plated copper wire | Extremely high temperature resistance, acid and alkali corrosion resistance, strong oxidation resistance, optimal anti-aging performance, suitable for extreme high temperature conditions. | Aerospace, military equipment, high-temperature industrial furnaces, new energy extreme working condition equipment. | High end customization, dedicated for extreme working conditions. |
For detailed information, please refer to --- How to Select The Conductor Material for UL 1332 Wire?
Company advantages
Zhejiang IRONFLON Wire&Cable Co., Ltd. is a self owned intellectual property enterprise that integrates research and development, manufacturing, sales, and commerce. It has been focusing on the research and production of fluororesin cables for many years and has become a large-scale production base for fluororesin high-temperature resistant wires and cables. Choosing us will provide you with comprehensive guarantees of quality, service, and efficiency
Service Advantage
A professional business team provides one-on-one communication to quickly respond to inquiries, quotations, and technical consultations.
Provide free samples to assist customers in verifying product compatibility.
Support dual modes of small-scale trial orders and large-scale long-term cooperation.
Advantages of product packaging and transportation
Standardized cardboard packaging, moisture-proof and pressure resistant, ensures the integrity of products during transportation.
Support customized packaging specifications (meters, labeling) according to customer requirements.
Long term cooperation with multiple international logistics companies, smooth sea and air transportation channels, and rich export experience.
customized service
Support full customization of wire diameter, color, printing, length, packaging, and other aspects.
Differentiated solutions for conductor material and insulation thickness can be provided based on specific application scenarios of customers.
Small batch minimum order to meet sample validation and new product development needs.
after-sales service
If there are quality issues after receiving the goods, free replacement or exchange will be provided.
Provide complete documents such as product testing reports and UL certificates to support customer customs declaration and certification.
Our customer service is available 24/7 to promptly address any questions customers may have during use.
production process
Adopting refined full process precision manufacturing technology, each process is strictly quality controlled to ensure product quality from the source:
Conductor precision twisting process: Using high-purity oxygen free copper substrate and precision twisting equipment for multi strand regular twisting, the conductor is compact without looseness, broken wires, or burrs, with uniform and stable conductivity, high tensile strength, and resistance to repeated bending and not easy to break.
Core advantages of the process: fully automated production reduces manual errors, refined quality control eliminates defects, product consistency and stability are extremely strong, suitable for customers' long-term mass production procurement, no batch quality differences, effectively reducing customer product failure rates and after-sales costs.
Certificates
We've got a lot of certificates.
Awarded " WSF World Standard Certificate ".
Awarded " Growth oriented Technology Enterprise of YueQing ".
Awarded " Science and Technology Innovation Enterprise Certificate of YueQing ".
Awarded " Certificate of sci-tech enterprises in Zhejiang Province ".
Awarded " Integrity Business Enterprise Certificate ".
Awarded " National High-tech Enterprise".
Awarded " Yueqing Patent Demonstration Enterprise".
Awarded " Yueqing Municipal Enterprise Technology Center".
Awarded " Provincial Small and Medium Technology Enterprise".
Awarded " Group Standard of Ethylene-Tetrafluoroethylene Copolymer for Wire and Cable and Optical Fiber Cable".
Awarded " Group Standard of High Voltage Battery Cable for New Energy Vehicle".
Awarded " Specialized and Specialized New Enterprise ".
Awarded " Provincial New Product".
And so on.
Collaboration Cases
With stable product quality and efficient international logistics service system, our company's UL1332 series products have been successfully exported to multiple countries and regions around the world, winning the long-term trust and cooperation of many overseas customers. Here are some typical cooperation cases:
61000 meter UL1332 wire shipped to Oman
Our company has completed the mass production and full shipment of 61000 meters of UL1332 Wire, exclusively for the wiring project of local new energy and industrial automation equipment in Oman. Large scale orders rely on the advantages of our fully automated production line to achieve standardized mass production, with strict control over wire wall thickness, eccentricity, flame retardancy, and electrical stability throughout the process. The entire batch of wires has no batch differences and the quality is uniformly up to standard. With sufficient production capacity reserves and mature cross-border packaging and transportation solutions, orders are efficiently delivered on schedule, helping local engineering projects to land smoothly and laying a solid foundation for long-term strategic cooperation.
FAQ
Q: What colors can be customized?
A: Support single color, color bar, and printing customization, with ample stock of regular colors.
Q: Can UL certification be provided?
A: Sure, all of our UL series products can provide corresponding UL certification documents and testing reports to help customers smoothly clear customs and obtain product certification.
Q: Is wire stripping easy? Will there be skin cracking?
A: Our UL1332 adopts high-quality FEP raw materials and precision shaping technology, with excellent toughness of the insulation layer. The special tool is easy to peel, and normal processing will not cause cracking, delamination, or peeling. It is suitable for automated mass production processing.
